DECKS & PORCHES

​

​

STANDAND FEATURES AND OPTIONS

​

Structural Specifications

• 40 psf live load / 10 psf dead load

• Footings: 12" diameter and 42" deep, poured concrete

• Hardware: Hot-dipped galvanized or stainless steel connectors.

• Deck tension ties

​

Framing

• Joist size     2x8     2x10     2x12

• Joist spacing     12" O.C     16" O.C.

• Beam size     (2)2x10     (3)2x10     (2)2x12     Glulam

• Post size     4x4     6x6​

​

Ledger Board

• Ledger size:     2x8     2x10     2x12

• Flashing:     Galvanized steel flashing

• ledger timber screws

​

Decking Material​

• Composite

• PVC​

•  5/4" Western red cedar decking

• 5/4" Treated cedar tone

​

​Decking Installation / Fastening / Method

• TimberTech Cortex color-matched plug screw system

• Hidden fastener clip system

• Face screwed decking

• Combination per manufacturer

​

Deck board layout / Butt joint option

• Continuous boards

• Staggered butt joints

• Breaker board installed

​

Railings

• Westbury aluminum railing - Master Pro Installer

​

Post wraps

• Westbury aluminum post wraps - Master Pro Installer



​Lighting​

• Post Cap Lighting

• Stair Riser Lights

• Under-Rail Lighting

• Recessed Deck / In-Deck Lights

• Accent / Strip Lighting

​

Power Options to Offer

• Low - voltage wired LED (most common)

• Solar lighting

• Plug-in transformer system

​

Deck drainage / Under-deck system

• ​No drainage system

• Under-deck drainage installed

​

Optional Upgrades

• Picture frame boarder

• Drink rail

• Breaker board

• Deck lighting

• Under deck drainage

• Privacy wall

​

​

​

​

​

​
